Product Summary
The TUSB3410IVF is a low-dropout(LDO), low-power linear regulator offers excellent ac performance with very low ground current. High power-supply rejection ratio (PSRR), low noise, fast start-up, and excellent line and load transient response are provided while consuming a very low 46μA (typical) ground current. The applications of the TUSB3410IVF include WiFi, WiMax, Printers, Cellular Phones, SmartPhones, Handheld Organizers, PDAs.
Parametrics
TUSB3410IVF absolute maximum ratings: (1)VIN range: -0.3 to +7.0V; (2)VEN range: -0.3 to VIN +0.3V; (3)VOUT range: -0.3 to VIN +0.3V; (4)VFB range: -0.3 to VFB (TYP) +0.3V; (5)Peak output current: Internally limited; (6)Continuous total power dissipation: See Dissipation Ratings Table; (7)Junction temperature range, TJ: -55 to +150℃; (8)Storage temperature range, TSTG: -55 to +150℃; (9)ESD rating, HBM: 2kV; (10)ESD rating, CDM: 500V.
Features
TUSB3410IVF features: (1)500mA Low Dropout Regulator with EN; (2)Low IQ: 46μA; (3)Multiple Output Voltage Versions Available; (4)High PSRR: 60dB at 1kHz; (5)Ultra-low Noise: 28μVRMS; (6)Fast Start-Up Time: 45μs; (7)Stable with a Low-ESR, 2.0μF Typical Output capacitance; (8)Excellent Load/Line Transient Response; (9)2% Overall Accuracy (Load/Line/Temp, VOUT > 2.2V); (10)Very Low Dropout: 280mV at 500mA; (11)2mm × 2mm SON-6 and 3mm × 3mm SON-8 Packages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TUSB3410IVF |
Texas Instruments |
USB Interface IC RS232/IrDA Ser-to-USB Converter |
Data Sheet |
|
|
||||||||||||
|
TUSB3410IVFG4 |
Texas Instruments |
USB Interface IC RS232/IrDA Ser-to-USB Converter |
Data Sheet |
|
|
||||||||||||
