Product Summary

The SMS3922-079LF is an 8 rated, low-cost plastic packaged Schottky diode. It is designed for general purpose use in RF applications. The SMS3922-079LF is fully characterized, including SPICE model parameters, and deliver tight parameter distribution, which minimizes performance variability. The applications of the SMS3922-079LF include High volume commercial detectors, mixers, switches, and digital pulse forming systems.

Parametrics

SMS3922-079LF absolute maximum ratings: (1)Reverse voltage c: Rated VB V; (2)Forward current IF: 50mA; (3)Power dissipation @ 25℃ lead temperature PD: 75mW; (4)Storage temperature TSTG:–65 to +150℃; (5)Operating temperature TA: –65 to +150℃; (6)Junction temperature TJ: +150℃.

Features

SMS3922-079LF features: (1)Tight parameter distribution; (2)Available as singles, pairs, and dual series pairs; (3)100 percent DC tested; (4)Packages rated MSL1, 260℃ per JEDEC J-STD-020.

Diagrams

SMS3922-079LF block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SMS3922-079LF
SMS3922-079LF
Skyworks Solutions, Inc.
Schottky (Diodes & Rectifiers) Ls=.7nH SC-79 Single
Data Sheet
0-1: $0.32
1-50: $0.30
50-100: $0.27
100-500: $0.23
