Product Summary

The SN75LVDS83BDGGR is a differential data line transceiver in the trade-standard footprint of the SN75LVDS83BDGGR with built-in protection against high-energy noise transients. This feature of SN75LVDS83BDGGR provides a substantial increase in reliability for better immunity to noise transients coupled to the data cable over most existing devices. Use of SN75LVDS83BDGGR provides a reliable low-cost direct-coupled (with no isolation transformer) data line interface without requiring any external components.

Parametrics

SN75LVDS83BDGGR absolute maximum ratings: (1)Supply voltage, VCC: -0.5 V to 7 V; (2)Continuous voltage range at any bus termina: -15 V to 15 V; (3)Data input/output voltage: -0.3 V to 7 V; (4)Receiver output current, IO: ±20 mA; (5)Electrostatic discharge: Contact discharge (IEC61000-4-2) A, B, GND: 30 kV, Air discharge (IEC61000-4-2) A, B, GND: 15 kV, Human body model (see Note 3) A, B, GND: 15 kV, All pins: 3 kV, All terminals (Class 3A): 8 kV, All terminals (Class 3B): 1200 V; (6)Continuous total power dissipation: Internally Limited.

Features

SN75LVDS83BDGGR features: (1)Integrated Transient Voltage Suppression; (2)ESD Protection for Bus Terminals Exceeds: ±30 kV IEC 61000-4-2, Contact Discharge, ±15 kV IEC 61000-4-2, Air-Gap Discharge, ±15 kV EIA/JEDEC Human Body Model; (3)Circuit Damage Protection of 400-W Peak (Typical) Per IEC 61000-4-5; (4)Controlled Driver Output-Voltage Slew Rates Allow Longer Cable Stub Lengths; (5)250-kbps in Electrically Noisy Environments; (6)Open-Circuit Fail-Safe Receiver Design; (7)1/4 Unit Load Allows for 128 Devices Connected on Bus; (8)Thermal Shutdown Protection; (9)Power-Up/-Down Glitch Protection.

Diagrams

SN75LVDS83BDGGR schematic

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SN75LVDS83BDGGR
SN75LVDS83BDGGR

Texas Instruments

Bus Transmitters FlatLink 10-135MHz Transmitter

Data Sheet

0-1: $3.43
1-25: $2.89
25-100: $2.65
100-250: $2.42
