Product Summary

The SN74LVC1G32YZPR is a quadruple 2-input positive-nand gate. It is designed for 1.65-V to 3.6-V VCC operation. Inputs can be driven from either 3.3-V or 5-V devices. This feature of the SN74LVC1G32YZPR allows the use of these devices as translators in a mixed 3.3-V/5-V system environment.

Parametrics

SN74LVC1G32YZPR absolute maximum ratings: (1)VCC Supply voltage range: –0.5 to 6.5 V; (2)VI Input voltage range: –0.5 to 6.5 V; (3)VO Output voltage range: –0.5 to VCC + 0.5 V; (4)IIK Input clamp current VI < 0: –50 mA; (5)IOK Output clamp current VO < 0: –50 mA; (6)IO Continuous output current: ±50 mA; (7)VCC Continuous current through GND: ±100 mA; (8)Tstg Storage temperature range: –65 to 150 ℃; (9)Ptot Power dissipation TA = –40℃ to 125℃: 500 mW.

Features

SN74LVC1G32YZPR features: (1)Operate From 1.65 V to 3.6 V; (2)Latch-Up Performance Exceeds 250 mA Per JESD 17; (3)Specified From –40℃ to 85℃, –40℃ to 125℃, and –55℃ to 125℃; (4)ESD Protection Exceeds JESD 22; (5)Inputs Accept Voltages to 5.5 V; (6)Max tpd of 4.3 ns at 3.3 V; (7)Typical VOLP (Output Ground Bounce) <0.8 V at VCC = 3.3 V, TA = 25℃; (8)Typical VOHV (Output VOH Undershoot) >2 V at VCC = 3.3 V, TA = 25℃.

Diagrams

SN74LVC1G32YZPR diagaram
