Product Summary

The REF198GSZ-REEL is a precision band gap voltage reference uses a patented temperature drift curvature correction circuit and laser trimming of highly stable, thin-film resistors to achieve a very low temperature coefficient and high initial accuracy. The REF198GSZ-REEL is made up of micropower, low dropout voltage (LDV) devices, providing stable output voltage from supplies as low as 100 mV above the output voltage and consuming less than 45 μA of supply current. The applications of the REF198GSZ-REEL include Portable instruments, ADCs and DACs, Smart sensors, Solar-powered applications, Loop current-powered instruments.

Parametrics

REF198GSZ-REEL absolute maximum ratings: (1)Supply Voltage: -0.3 V to +18 V; (2)Output to GND: -0.3 V to VS + 0.3 V; (3)Output to GND Short-Circuit Duration: Indefinite; (4)Storage Temperature Range, PDIP, SOIC_N Package: -65℃ to +150℃; (5)Operating Temperature Range REF19x: -40℃ to +85℃; (6)Junction Temperature Range, PDIP, SOIC_N Package: -65℃ to +150℃; (7)Lead Temperature Range (Soldering 60 sec): 300℃.

Features

REF198GSZ-REEL features: (1)Initial accuracy: ±2 mV maximum; (2)Temperature coefficient: 5 ppm/℃ maximum; (3)Low supply current: 45 μA maximum; (4)Sleep mode: 15 μA maximum; (5)Low dropout voltage; (6)Load regulation: 4 ppm/mA; (7)Line regulation: 4 ppm/V; (8)High output current: 30 mA; (9)Short-circuit protection.
