LM5007MM/NOPB

150 mA, 100V, Step-Down Switching Regulator, Integrated N-Channel MOSFET, 8-MSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.19~0.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.19~0.70

PartNumber:: LM5007MM/NOPB

Brand:: National Semiconductor - NS | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Teven's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-06

From Other Seller

Part Number:LM5007MM/NOPB
US $0.19 - 0.70
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
TOP259EN

US $1.10 - 3.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM5007MM/NOPB Step Down Switching Regulator features all of the functions needed to implement a low cost, efficient, Buck bias regulator. This device is capable of driving a 150 mA load current from a 9.5V to 95V input source. The switching frequency of the LM5007MM/NOPB can exceed 600 kHz, depending on the input and output voltages. The output voltage may be set from 2.5V to 85V. This high voltage regulator contains an N-Channel buck switch and internal startup regulator. The LM5007MM/NOPB is easy to implement and is provided in the MSOP-8 and the thermally enhanced LLP-8 packages. The LM5007MM/NOPB is a well suited alternative to a high voltage monolithic or discrete linear solution where the power loss becomes unacceptable. The regulator LM5009MM+ operation is based on a control scheme using an ON time inversely proportional to VIN. This feature allows the operating frequency to remain relatively constant over load and input voltage variations. The applications of the LM5007MM/NOPB are: Heat sink eliminator for classic linear regulator applications, 12V, 24V, 36V, and 48V rectified AC systems, 42V Automotive, Non-isolated AC mains charge coupled supplies, LED Current Source.

Parametrics

LM5007MM/NOPB absolute maximum ratings: (1)VIN to RTN: -0.3V to 100V; (2)BST to RTN: -0.3V to 114V; (3)SW to RTN (Steady State): -1V; (4)ESD Rating, Human Body Model: 2kV; (5)BST to VCC: 100V; (6)BST to SW: 14V; (7)VCC to RTN: 14V; (8)All Other Inputs to RTN: -0.3 to 7V.

Features

LM5007MM/NOPB features: (1)Integrated N-Channel MOSFET; (2)Guaranteed 150 mA output current capability; (3)Ultra-Fast Transient Response; (4)No loop compensation required; (5)Vin feed forward provides constant operating frequency; (6)Switching frequency can exceed 600 kHz; (7)Highly efficient operation; (8)2% accurate 2.5V feedback from -40℃ to 125℃; (9)Internal startup regulator; (10)Intelligent current limit protection; (11)External shutdown control; (12)Thermal shutdown; (13)MSOP-8 and thermally enhanced LLP packages.
