Product Summary

The LM4835MT is a 3W Audio Power Amplifier with Shutdown Mode.

Parametrics

LM4835MT absolute maximum ratings: (1)Supply Voltage: 6.0V; (2)Supply Temperature: -65℃ to +150℃; (3)Input Voltage: -0.3V to VDD to +0.3V; (4)Power Dissipation: Internally Limited; (5)ESD Susceptibility: 5000V; (6)ESD Susceptibility: 250V; (7)Junction Temperature: 150℃; (8)Temperature Range TMIN ≤ TA ≤ TMAX: -40℃ ≤ TA ≤ 85℃; (9)Supply Voltage VDD: 2.0V to 5.5V; (10)IDD Quiescent Power Supply Current VIN = 0V, Io = 0A: 10.0 mA; (11)ISD Shutdown Current VPIN1 = VDD: 2 μA; (12)VOS Output Offset Voltage VIN = 0V: 50 mV; (13)Po Output Power THD = 1%, f = 1kHz RL = 8Ω: 1.2 W; (14)Po Output Power THD+N = 10%, f = 1kHz RL = 8Ω: 1.5 W; (15)THD+N Total Harmonic Distortion+Noise 20Hz ≤ f ≤ 20kHz, AVD = 2 RL = 8Ω, PO = 1W: 0.25%; (16)PSRR Power Supply Rejection Ratio VDD = 4.9V to 5.1V: 60 dB.

Features

LM4835MT features: (1)Pin compatible with the LM4861; (2)No output coupling capacitors, bootstrap capacitors, or snubber circuits required; (3)Unity-gain stable; (4)LLP, MSOP, SO, or DIP packaging; (5)External gain configuration capability.

Diagrams

LM4835MT pin configuration
