LM4040CIM3X-8.2

LM4040CIM3X-8.2, shunt voltage reference, SOT23, -10 to 25mA, 35mV, 45mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.19~0.71 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.19~0.71

PartNumber:: LM4040CIM3X-8.2

Brand:: National Semiconductor - NS | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Teven's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:LM4040CIM3X-8.2
US $0.19 - 0.71
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM4040CIM3X-8.2 shunt voltage reference is a versatile, easy-to-use reference that caters to a vast array of applications. The 2-pin fixed-output device requires no external capacitors for operation and is stable with all capacitive loads. Additionally, the reference offers low dynamic impedance, low noise, and low temperature coefficient to ensure a stable output voltage over a wide range of operating currents and temperatures. The LM4040CIM3X-8.2 uses fuse and Zener-zap reverse breakdown voltage trim during wafer sort to offer four output voltage tolerances, ranging from 0.1% (max) for the A grade to 1% (max) for the D grade. Packaged in space-saving SC-70 and SOT-23-3 packages and requiring a minimum current of 45mA (typ), the LM4040CIM3X-8.2 also is ideal for portable applications.

Parametrics

LM4040CIM3X-8.2 absolute maximum ratings over free-air temperature range: (1)IZ, Continuous cathode current: –10 to 25mA; (2)θJA, Package thermal impedance: DBZ package: 206℃/W max; DCK package: 252℃/W max; LP package: 156℃/W max; (3)TJ, Operating virtual junction temperature: 150 °C max; (4)Tstg, Storage temperature range: –65 to 150℃.

Features

LM4040CIM3X-8.2 features: (1)Fixed Output Voltages of 2.048 V, 2.5 V, 3 V, 4.096 V, 5 V, 8.192 V, and 10 V; (2)Tight Output Tolerances and Low Temperature Coefficient: Max 0.1%, 100ppm/℃ – A Grade; Max 0.2%, 100ppm/℃ – B Grade; Max 0.5%, 100ppm/℃ – C Grade; Max 1.0%, 150ppm/℃ – D Grade.; (3)Low Output Noise: 35mVRMS Typ; (4)Wide Operating Current Range: 45mA Typ to 15mA; (5)Stable With All Capacitive Loads; No Output Capacitor Required; (6)Available in Extended Temperature Range: –40 to 125℃.
