Product Summary

The LM2621MM/NOPB is a high efficiency, step-up DC-DC switching regulator for battery-powered and low input voltage systems. It accepts an input voltage between 1.2V and 14V and converts it into a regulated output voltage. The output voltage can be adjusted between 1.24V and 14V. It has an internal 0.17W N-Channel MOSFET power switch. Efficiencies up to 90% are achievable using the LM2621MM/NOPB. The high switching frequency (adjustable up to 2MHz) of the LM2621MM/NOPB allows for tiny surface mount inductors and capacitors. Because of the unique constant-duty-cycle gated oscillator topology very high efficiencies are realized over a wide load range. The supply current is reduced to 80μA because of the BiCMOS process technology. In the shutdown mode, the supply current is less than 2.5μA. The LM2621MM/NOPB is available in a Mini-SO-8 package. This package uses half the board area of a standard 8-pin SO and has a height of just 1.09 mm.

Parametrics

LM2621MM/NOPB absolute maximum ratings: (1)SW Pin Voltage: -0.5 V to 14.5V; (2)BOOT, VDD, EN and FB Pins: -0.5V to 10V; (3)FREQ Pin: 100μA; (4)θJA (Note 2): 240℃/W; (5)TJmax (Note 2): 150℃; (6)Storage Temperature Range: -65℃ to +150℃; (7)Lead Temp. (Soldering, 5 sec): 260℃; (8)Power Dissipation (TA=25℃)(Note 2): 500mW; (9)ESD Rating (Note 3): 2kV.

Features

LM2621MM/NOPB features: (1)Small Mini-SO8 Package (Half the Footprint of Standard 8-PiSO Package); (2)1.09 mm Package Height; (3)Up to 2 MHz Switching Frequency; (4)1.2V to 14V Input Voltage; (5)1.24V - 14V Adjustable Output Voltage; (6)Up to 1A Load Current; (7)0.17 W Internal MOSFET; (8)Up to 90% Regulator Efficiency; (9)80 μA Typical Operating Current; (10)<2.5μA Guaranteed Supply Current In Shutdown.

Diagrams

LM2621MM/NOPB block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM2621MM/NOPB
LM2621MM/NOPB

National Semiconductor (TI)

DC/DC Switching Controllers LOW INP VLTG,STEP-UP DC-DC

Data Sheet

0-1: $1.15
1-25: $0.93
25-100: $0.84
100-250: $0.74
