TPS3823-25QDBVRQ1

TPS3823-25QDBVRQ1, processor supervisory circuit, SOT, 6 V, ±10 mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.59~1.99 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.59~1.99

PartNumber:: TPS3823-25QDBVRQ1

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Teven's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:TPS3823-25QDBVRQ1
US $0.59 - 1.99
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TPS3823-25QDBVRQ1 is a supervisor provides circuit initialization and timing supervision, primarily for DSP and processor-based systems. During power-on, RESET is asserted when supply voltage VDD becomes higher than 1.1 V. Thereafter, the supply voltage supervisor monitor VDD and keeps RESET active as long as VDD remains below the threshold voltage VIT. An internal timer delays the return of the output to the inactive state (high) to ensure proper system reset. The delay time, td, starts after VDD has risen above the threshold voltage VIT. When the supply voltage of the TPS3823-25QDBVRQ1 drops below the threshold voltage VIT-, the output becomes active (low)again. No external components are required. The TPS3823-25QDBVRQ1 has a fixed-sense threshold voltage VIT- set by an internal voltage divider.

Parametrics

TPS3823-25QDBVRQ1 absolute maixmum ratings: (1)Supply voltage, VDD: 6 V; (2)RESET, RESET, MR, WDI: -0.3 V to (VDD + 0.3 V); (3)Maximum low output current, IOL: 5 mA; (4)Maximum high output current, IOH: -5 mA; (5)Input clamp current range, IIK (VI < 0 or VI > VDD): ±10 mA; (6)Output clamp current range, IOK (VO < 0 or VO > VDD): ±10 mA; (7)Continuous total power dissipation: See Dissipation Rating Table; (8)Operating free-air temperature range, TA: -40℃ to 85℃; (9)Storage temperature range, Tstg: -65℃ to 150℃; (10)Soldering temperature: 260℃.

Features

TPS3823-25QDBVRQ1 features: (1)Power-On Reset Generator With Fixed Delay Time of 200 ms(TPS3823/4/5/8) or 25 ms (TPS3820); (2)Manual Reset Input (TPS3820/3/5/8); (3)Reset Output Available in Active-Low (TPS3820/3/4/5), Active-High (TPS3824) and Open-Drain (TPS3828); (4)Supply Voltage Supervision Range: 2.5 V, 3 V, 3.3 V, 5 V; (5)Watchdog Timer (TPS3820/3/4/8); (6)Supply Current of 15 μA (Typ); (7)SOT23-5 Package; (8)Temperature Range: -40℃ to 85℃.
