MAT14ARZ-R7

NPN dual monolithic transistor, MAT14ARZ-R7, DIP, 40 V, 20 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $5.70~13.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $5.70~13.80

PartNumber:: MAT14ARZ-R7

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Teven's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:MAT14ARZ-R7
US $5.70 - 13.80
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAT14ARZ-R7 is an NPN dual monolithic transistor. It is optimized for very low noise, low drift, and low rBE. Precision Monolithics’ exclusive Silicon Nitride Triple-Passivation process stabilizes the critical device parameters over wide ranges of temperature and elapsed time. Also, the high current gain (hFE) of the MAT14ARZ-R7 is maintained over a wide range of collector current. Exceptional characteristics of the MAT14ARZ-R7 include offset voltage of 50 µV max (A/E grades) and 150 uV max F grade.

Parametrics

MAT14ARZ-R7 absolute maximum ratings: (1)Collector-Base Voltage (BVCBO): 40 V; (2)Collector-Emitter Voltage (BVCEO): 40 V; (3)Collector-Collector Voltage (BVCC): 40 V; (4)Emitter-Emitter Voltage (BVEE): 40 V; (5)Collector Current (IC): 20 mA; (6)Emitter Current (IE): 20 mA; (7)Total Power Dissipation: 1.8 W; (8)Operating Temperature Range: –55℃ to +125℃; (9)Operating Junction Temperature: –55℃ to +150℃; (10)Storage Temperature: –65℃ to +150℃; (11)Lead Temperature (Soldering, 60 sec): +300℃; (12)Junction Temperature: –65℃ to +150℃.

Features

MAT14ARZ-R7 features: (1)Low Offset Voltage: 50 mV max; (2)Low Noise Voltage at 100 Hz, 1 mA: 1.0 nV/√Hz max; (3)High Gain (hFE): 500 min at IC = 1 mA, 300 min at IC = 1 mA; (4)Excellent Log Conformance: rBE . 0.3 V; (5)Low Offset Voltage Drift: 0.1 uV/8℃ max; (6)Improved Direct Replacement for LM194/394; (7)Available in Die Form.
