Product Summary

The FODB100 is a single channel microcoupler in a Ball Grid Array (BGA) package. The device consists of an aluminum gallium arsenide (AlGaAs) infrared emitting diode driving a silicon phototransistor. The applications of the FODB100 are Primarily suited for DC-DC converters and For ground loop isolation, signal to noise isolation Communications chargers, adapters, Consumer appliances, set top boxes, Industrialpower supplies, motor control.

Parametrics

FODB100 absolute maximum ratings: (1)Storage Temperature, TSTG: -55 to +150℃; (2)Operating Temperature, TOPR: -40 to +125℃; (3)Junction Temperature, Tj: 130℃; (4)Continuous Forward Current, IF (avg): 30 mA; (5)Reverse Input Voltage, VR: 6V; (6)Power Dissipation, PD: 40 mW.

Features

FODB100 features: (1)Low profile package; (2)Land pattern allows for optimum board space savings; (3)High Current Transfer Ratio (CTR) at low IF; (4)Minimum isolation distance of 0.45mm; (5)High steady state isolation voltage of 2500Vrms; (6)Data rates up to 120Kbit/s (NRZ); (7)Minimum creepage distance of 2mm; (8)Wide operating temperature range of -40 to +125℃; (9)Available in tape and reel quantities of 3000 units; (10)Applicable to Pb-free Infrared Ray re?ow (260℃ max); (11)UL, C-UL approved; VDE pending.

Diagrams

FODB100 schematic

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
FODB100
FODB100
Fairchild Semiconductor
High Speed Optocouplers Sngl Ch MICROCOUPLER
Data Sheet
Negotiable
FODB100V
FODB100V
Fairchild Semiconductor
High Speed Optocouplers Single Channel Microcoupler
Data Sheet
Negotiable
