BA33DD0WHFP-TR

low-saturation regulator, TO-252, -0.3～+35 V, 2000 mW, 2A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.78~2.89 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.78~2.89

PartNumber:: BA33DD0WHFP-TR

Brand:: Rohm - Rohm | Pack: TO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Teven's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-31

From Other Seller

Part Number:BA33DD0WHFP-TR
US $1.78 - 2.89
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BA33DD0WHFP-TR is a low-saturation regulator, available for output s up to 2A/1A. ROHM has a wide output voltage range and package lineup with and without shutdown switches. This IC BA33DD0WHFP-TR has a built-in over-current protection circuit that prevents the destruction of the IC due to output short circuits, a thermal shut-down circuit that protects the IC from damage due to overloading and an over-voltage protection circuit that protects the IC from surges generated in the power supply line of the IC. The applications of the BA33DD0WHFP-TR include Used in DSP power supplies for DVD and CD players, FPDs, televisions, personal computers or any other consumer device.

Parametrics

BA33DD0WHFP-TR absolute maximum ratings: (1)Input Power Supply Voltage, Vcc: -0.3～+35 V; (2)Power Dissipation, Pd: 2000 mW; (3)Operating Temperature Range, Topr: -40～+125℃; (4)Ambient Storage Temperature, Tstg: -55～+150℃; (5)Junction Temperature Tjmax: +150℃; (6)Output Control Terminal Voltage, VCTL: -0.3～+Vcc; (7)Voltage Applied to the Tip, Vcc peak: +50 V.

Features

BA33DD0WHFP-TR features: (1)Maximum output current : 2A; (2)±1% highly accurate output voltag; (3)Low saturation with PNP output; (4)Built-in over-current protection circuit that prevents the destruction of the IC due to output short circuits; (5)Built-in thermal shutdown circuit for protecting the IC from damage due to overloading ; (6)Built-in over- voltage protection circuit that prevents the destruction of the IC due to power supply surges.
