Product Summary

The AD607ARSZ-REEL is a 3 V low power receiver IF subsystem for operation at input frequencies as high as 500 MHz and IFs from 400 kHz to 12 MHz. It consists of a mixer, IF amplifiers, I and Q demodulators, a phase-locked quadrature oscillator, AGC detector, and a biasing system with external power-down. The applications of the AD607ARSZ-REEL are GSM, CDMA, TDMA, and TETRA Receivers, Satellite Terminals and Battery-Powered Communications Receivers.

Parametrics

AD607ARSZ-REEL absolute maximum ratings: (1)Supply Voltage VPS1, VPS2 to COM1, COM2: +5.5 V; (2)Internal Power Dissipation: 600 mW; (3)2.7 V to 5.5 V Operating Temperature Range: –25 to +85℃; (4)4.5 V to 5.5 V Operating Temperature Range: –40 to +85℃; (5)Storage Temperature Range: –65 to +150℃; (6)Lead Temperature Range (Soldering 60 sec): +300℃.

Features

AD607ARSZ-REEL features: (1)Complete Receiver on a Chip: Monoceiver Mixer; (2)Linear IF Amplifier; (3)Linear-in-dB Gain Control; (4)MGC or AGC with RSSI Output; (5)Quadrature Demodulator; (6)On-Board Phase-Locked Quadrature Oscillator; (7)Demodulates IFs from 400 kHz to 12 MHz; (8)Can Also Demodulate AM, CW, SSB; (9)Low Power.

Diagrams

AD607ARSZ-REEL block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD607ARSZ-REEL
AD607ARSZ-REEL

IC RECEIVER IF SUBSYS LP 20SSOP
Data Sheet
0-1500: $2.72
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD600ARZ
AD600ARZ

IC AMP VGA DUAL LN 50MA 16SOIC
Data Sheet
0-1: $21.17
1-10: $19.80
10-100: $17.16
100-250: $16.02
250-500: $15.26
AD607ARSZ-REEL
AD607ARSZ-REEL

IC RECEIVER IF SUBSYS LP 20SSOP
Data Sheet
0-1500: $2.72
AD606JN
AD606JN

IC AMP LOG LP 1.2MA 16DIP
Data Sheet
0-7: $29.48
AD605-EB
AD605-EB
Analog Devices Inc
BOARD EVAL/DEMO ADJ GAIN AD605
Data Sheet
Negotiable
AD605AN
AD605AN
Analog Devices Inc
IC AMP DUAL ADJ GAIN 5V 16-DIP
Data Sheet
1-25: $9.47
AD605-02
AD605-02
NVE Corp/Sensor Products
SENSOR MAG SW 40G STANDARD 8SOIC
Data Sheet
1-552: $1.62
