ABA-52563-TR1G

50-ohm, silicon monolithic amplifier, SOT-363, 0.4W, +20dBm, +7V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.51~1.33 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.51~1.33

PartNumber:: ABA-52563-TR1G

Brand:: AVAGO TECHNOLOGIES LIMITED - Avago | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Teven's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:ABA-52563-TR1G
US $0.51 - 1.33
DAD1000

US $2.50 - 3.50 / Piece
(0) Remove
MJ16018

US $1.80 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ABA-52563-TR1G is an economical, easy-to-use, internally 50-ohm matched silicon monolithic amplifier that offers excellent gain and flat broadband response from DC to 3.5 GHz. Packaged in an ultraminiature industry-standard SOT-363 package, it requires half the board space of a SOT-143 package. The ABA-52563-TR1G is suitable for cellular, cordless, special mobile radio, PCS, ISM, wireless LAN, DBS, TVRO, and TV tuner applications.

Parametrics

ABA-52563-TR1G absolute maximum ratings: (1)Vcc Device Voltage, RF output to ground (T = 25℃): +7V; (2)Pin CW RF Input Power (Vcc = 5V): +20dBm; (3)Pdiss Total Power Dissipation: 0.4W; (4)Tj, Junction Temperature: 150℃; (5)TSTG Storage Temperature: -65 to 150℃.

Features

ABA-52563-TR1G features: (1)Operating frequency: DC ~ 3.5 GHz; (2)21.5 dB gain; (3)VSWR < 2.0 throughout operating frequency; (4)9.8 dBm output P1dB; (5)3.3 dB noise figure; (6)Unconditionally stable; (7)Single 5V supply (Id = 35 mA); (8)Lead-free option available.
