Product Summary
The OPA2180IDR is a high precision monolithic dielectrically isolated FET (Difet ) operational amplifier. Outstanding performance characteristics allow its use in the most critical instrumentation applications. The applications of the OPA2180IDR are (1)precision instrumentation; (2)data acquisition; (3)test equipment; (4)professional audio equipment; (5)medical equipment; (6)detector arrays.
Parametrics
OPA2180IDR absolute maximum ratings: (1)Supply: ±18VDC; (2)Internal Power Dissipation (TJ ≤ +175℃): 500mW; (3)Differential Input Voltage: Total VCC; (4)Input Voltage Range: ±VCC; (5)Storage Temperature Range: –65 to +150℃; (6)Operating Temperature Range: –55 to +125℃; (7)Lead Temperature (soldering, 10s): +300℃; (8)Output Short Circuit to Ground (+25℃): Continuous; (9)Junction Temperature: +175℃.
Features
OPA2180IDR features: (1)low noise: 100% Tested, 8nV/√Hz max at 10kHz; (2)low bias current: 4pA max; (3)low offset: 500μV max; (4)low drift: 2.8μV/℃; (5)high open-loop gain: 114dB min; (6)high common-mode rejection: 96dB min.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() OPA2180IDR |
![]() Texas Instruments |
![]() Operational Amplifiers - Op Amps Low Noise,RRO,36V 0-Drift Op Amp |
![]() Data Sheet |
![]()
|
|
||||||||||||||
